How to Compare Two COMSOL Solutions Using Join Dataset
You changed the mesh. Or you changed a parameter. The new result looks "about the same" as the old one. But how much is "about"? And where in the model is the change biggest? Most users open two plots side by side and compare them by eye. This is slow, and it hides small but important differences. COMSOL has a better tool for this job: the Join dataset. It combines two solutions into one dataset, so you can plot the difference directly. What the Join Dataset Does The Join dat
Jan Simkovsky
Oct 303 min read


How to Inspect the Mesh Inside a 3D Domain in COMSOL Multiphysics
When you build a mesh in a 3D model, COMSOL shows you only the outside of it. You see the surface triangles, but you do not see what happens inside the domain. Are the elements inside fine enough? Does the boundary layer grow correctly into the volume? Where are the bad elements? The meshed complex structure example. How to inspect the mesh in detail? You can look inside the mesh using a Mesh plot in Results. In this article, you will learn how to do it step by step. Step 1:
Jan Simkovsky
Oct 253 min read


How to Unify the Color Scale in a COMSOL Plot Group
When you plot two results in COMSOL, the colors often do not match. Each plot picks its own color range by default. This makes it hard to compare two plots side by side. Luckily, COMSOL has a simple fix for this. In this article, you will learn how to lock the color scale. This way, both plots use the same colors for the same values. Why the Colors Do Not Match By default, COMSOL sets the color range automatically for each color plot. It looks at your data and picks a minimum
Jan Simkovsky
Sep 302 min read


How to Calculate Any Integral in COMSOL Multiphysics
How to calculate an integral in COMSOL Multiphysics with some step-by-step examples. An integral is very often needed when you need to compute some user-defined postprocessing variables, e.g., lift, drag, heat flux, or any other.
Jan Simkovsky
Aug 283 min read


Stop Guessing: How to Turn Off Interpolation in COMSOL Plots
Every COMSOL plot you've ever admired for its gorgeous, gradient-smooth color field has been touched up. COMSOL averages your results before it draws them. The smooth field on your screen is not exactly what the solver computed. It's called smoothing. How to work with smoothing and what are the best practices?
Jan Simkovsky
Aug 163 min read


Side-by-Side Animations in COMSOL: Visualize Multiple Plots in One Window
When you run a time-dependent coupled simulation, let's say, a Joule-heating problem where both temperature and electric potential evolve over time, exporting two separate animations and watching them separately is clunky. COMSOL gives you at least two clean ways to place multiple plot groups side by side inside a single animation. This article walks through both: the modern Array approach available since COMSOL 5.x, and the classic Deformation-node offset trick that still wo
Jan Simkovsky
Jul 285 min read
